The Hinomoto E23 is a tractor rated at approximately 23 horsepower, positioning it at the lower end of its class. Produced between 1977 and 1979, this model features a 2-cylinder diesel liquid-cooled engine and two-wheel drive with a 12-speed gearbox. The operating weight of the Hinomoto E23 is listed as 928 kilograms, and it is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Weight
928 kg
Catalogue coverage
Variants represented
2
Richest spec table
22 rows
Recorded power
23 hp
Recorded weight
928 kg
Transmissions
12-speed
Production years
1977-1979
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerHinomotoReference
Compact Utility tractorReference
Built in JapanReference
The Hinomoto E23 is similar to the Allis 5020, the Simplicity 9523, and the Massey-Ferguson 210.Reference
Two-wheel driveReference
Engine
Toyosha 1.3L 2-cyl dieselReference
Engine17.2 kWReference
Toyosha P126Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke92 x 95 mmReference
Power17.2 kWReference
Transmission
12-speedReference
Gears12 forward and 3 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear PTO Type547/875/1000Reference
Dimensions
Weight928 kgReference
Length256 cmReference
Width121 cmReference
Height132 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
