Tractor · Unverified

Hinomoto E382

Name: Hinomoto E382
Brand: Hinomoto

Hinomoto E382 — Compact Utility tractor · 40 hp. Reference specifications; pending source verification.

The Hinomoto E382 is a tractor model with a rated power output of 40 hp, positioning it at the lighter end of its class. It features a 3-cylinder diesel liquid-cooled engine paired with four-wheel drive and a 12-speed gearbox. The tractor's operating weight is 1584 kg, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

40 hp

Weight

1584 kg

Catalogue coverage

Variants represented

Richest spec table

61 rows

Recorded power

40 hp

Recorded weight

1584 kg

Transmissions

12-speed gear

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerHinomotoReference

Compact Utility tractorReference

Two-wheel driveReference

Power steeringReference

Mechanical wet disc brakesReference

Open operator station. ROPS available.Reference

Variants

E3822WDReference

E3844WDReference

Engine

Toyosha 1.9L 3-cyl dieselReference

Fuel tank32.2 LReference

Engine (gross)30.1 kWReference

Engine (net)28.0 kWReference

Toyosha 3S200Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.9 LReference

Bore/Stroke92 x 100 mmReference

Power (net)28.0 kWReference

Power (gross)30.1 kWReference

Fuel systemindirect injectionReference

Compression23.1:1Reference

Rated RPM2500Reference

Torque127.5 NmReference

Torque RPM1700Reference

StarterelectricReference

Starter volts12Reference

Oil capacity5.0 LReference

Coolant capacity8.0 LReference

Transmission

12-speed gearReference

24-speed creeperReference

TypegearReference

Gears12 forward and 4 reverseReference

Oil capacity40.0 LReference

TypecreeperReference

Gears24 forward and 8 reverseReference

PTO & Hydraulics

PTO (claimed)25.7 kWReference

Typeopen centerReference

Rear TypeIReference

Controlposition and draft controlReference

Rear lift (at ends)1515 kgReference

Rear PTOtransmissionReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Dimensions

Wheelbase183 cmReference

Weight1584 kgReference

Front tire5.50-16Reference

Rear tire12.4-28Reference

Standard tires (ag)Front: 5.50-16. Rear: 12.4-28Reference

Optional tires (ag)Front: 5.50-16. Rear: 13.6-26Reference

Length311 cmReference

Width104 cmReference

Height (steering wheel)152 cmReference

Height (exhaust)195 cmReference

Ground clearance37 cmReference

Front tread120 to 151 cmReference

Rear tread118 to 156 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps35Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
