Tractor · Unverified
Hinomoto E384
Hinomoto E384 — Compact Utility tractor · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
1650 kg
Hover a source tag to verify
Overview
ManufacturerHinomotoReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Open operator station. ROPS available.Reference
Variants
E3822WDReference
E3844WDReference
Engine
Toyosha 1.9L 3-cyl dieselReference
Fuel tank32.2 LReference
Engine (gross)30.1 kWReference
Engine (net)28.0 kWReference
Toyosha 3S200Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.9 LReference
Bore/Stroke92 x 100 mmReference
Power (net)28.0 kWReference
Power (gross)30.1 kWReference
Fuel systemindirect injectionReference
Compression23.1:1Reference
Rated RPM2500Reference
Torque127.5 NmReference
Torque RPM1700Reference
StarterelectricReference
Starter volts12Reference
Oil capacity5.0 LReference
Coolant capacity8.0 LReference
Transmission
12-speed gearReference
24-speed creeperReference
TypegearReference
Gears12 forward and 4 reverseReference
Oil capacity40.0 LReference
TypecreeperReference
Gears24 forward and 8 reverseReference
PTO & Hydraulics
PTO (claimed)25.7 kWReference
Typeopen centerReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1515 kgReference
Rear PTOtransmissionReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase180 cmReference
Weight1650 kgReference
Front tire8-16Reference
Rear tire12.4-28Reference
Standard tires (ag)Front: 8-16. Rear: 12.4-28Reference
Optional tires (ag)Front: 8-16. Rear: 13.6-26Reference
Length324 cmReference
Width104 cmReference
Height (steering wheel)160 cmReference
Height (exhaust)197 cmReference
Ground clearance38 cmReference
Front tread151 to 180 cmReference
Rear tread118 to 156 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps35Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
