Tractor · 1972Unverified
Hinomoto HB-501 Combac
Hinomoto HB-501 Combac — Compact Utility tractor · 17 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
1050 kg
Hover a source tag to verify
Overview
ManufacturerHinomotoReference
Compact Utility tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Toyosha 0.6L 1-cyl gasolineReference
Engine (gross)12.7 kWReference
Toyosha TE-150Reference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement0.6 LReference
Power (gross)12.7 kWReference
Rated RPM2800Reference
Starter typeelectricReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
Dimensions
Wheelbase109 cmReference
Weight1050 kgReference
Length368 cmReference
Width109 cmReference
Hinomoto HB-501 attachments
backhoeReference
Hinomoto Backhoe
Backhoe typeHinomoto BackhoeReference
Digging depth213 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
