The Hinomoto MB-1500 is a compact tractor model with a rated output of 17 hp. It is powered by a 1-cylinder petrol air-cooled engine, which drives through a 6-speed gearbox and two-wheel drive configuration. The model weighs approximately 464 kg, and it is designed for small-scale farming and land management tasks covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
464 kg
Catalogue coverage
Variants represented
2
Richest spec table
31 rows
Recorded power
17 hp
Recorded weight
464 kg
Transmissions
6-speed gear
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerHinomotoReference
Compact Utility tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
MB-501backhoe tractorReference
Engine
Toyosha 0.6L 1-cyl gasolineReference
Engine (gross)12.7 kWReference
Toyosha TE-150Reference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement0.6 LReference
Power (gross)12.7 kWReference
Rated RPM2800Reference
Starter typeelectricReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
Typeopen centerReference
Rear lift449 kgReference
Dimensions
Wheelbase109 cmReference
Weight464 kgReference
Front tire4.00x9Reference
Rear tire7.00x16Reference
Ag front4.00x9Reference
Ag rear7.00x16Reference
Length189 cmReference
Width105 cmReference
Height (steering wheel)117 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
