Tractor · Unverified
Hinomoto MB-1500
Hinomoto MB-1500 — Compact Utility tractor · 17 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
464 kg
Hover a source tag to verify
Overview
ManufacturerHinomotoReference
Compact Utility tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
MB-501backhoe tractorReference
Engine
Toyosha 0.6L 1-cyl gasolineReference
Engine (gross)12.7 kWReference
Toyosha TE-150Reference
gasolineReference
1-cylinderReference
air-cooledReference
Displacement0.6 LReference
Power (gross)12.7 kWReference
Rated RPM2800Reference
Starter typeelectricReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
Typeopen centerReference
Rear lift449 kgReference
Dimensions
Wheelbase109 cmReference
Weight464 kgReference
Front tire4.00x9Reference
Rear tire7.00x16Reference
Ag front4.00x9Reference
Ag rear7.00x16Reference
Length189 cmReference
Width105 cmReference
Height (steering wheel)117 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
