Tractor · 1979Unverified
Hinomoto Westerner E180
Hinomoto Westerner E180 — E100 Series · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
1623 to 1827 pounds
Hover a source tag to verify
Overview
ManufacturerHinomotoReference
Compact Utility tractorReference
Built in JapanReference
Two- or four-wheel driveReference
Open operator station.Reference
Engine
Toyosha 1.1L 2-cyl dieselReference
Fuel tank24.6 LReference
Engine14.7 kWReference
Toyosha S-107Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.1 LReference
Bore/Stroke88 x 88 mmReference
Power14.7 kWReference
Fuel systemindirect injectionReference
Air cleanerdryReference
Pre-heatingglow plugsReference
Compression23:1Reference
Rated RPM2400Reference
StarterelectricReference
Starter volts12Reference
Oil capacity3.2 LReference
Coolant capacity4.0 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
2WD Oil capacity16.0 LReference
4WD Oil capacity16.9 LReference
Three gears, plus reverse, in two ranges.Reference
PTO & Hydraulics
Typeopen centerReference
Pump flow19.7 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift562 kgReference
Rear PTO Type540 (1.375)Reference
Dimensions
2WD Wheelbase139 cmReference
4WD Wheelbase139 cmReference
Weight1623 to 1827 poundsReference
Front tire4.00-12Reference
2WD Rear tire9.5/9-24Reference
2WD Standard tires (ag)Front: 4.00-12. Rear: 9.5/9-24Reference
4WD Standard tires (ag)Front: 6-14. Rear: 8.3/8-24Reference
2WD Length265 cmReference
4WD Length264 cmReference
2WD Width113 cmReference
4WD Width110 cmReference
2WD Weight736 kgReference
4WD Weight828 kgReference
2WD Clearance (front axle)32 cmReference
4WD Clearance (front axle)28 cmReference
2WD Clearance (drawbar)33 cmReference
4WD Clearance (drawbar)33 cmReference
2WD Front tread90 cmReference
4WD Front tread96 cmReference
Rear tread91 to 101 cmReference
2WD Steering wheel128 cmReference
4WD Steering wheel137 cmReference
E180 Serial Numbers
Location:Serial number plate on top of the transmission, in front of the gear shift lever.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Hinomoto E180 Height
2WD Exhaust179 cmReference
4WD Exhaust184 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
