The Hitachi TZ240 is a tractor model with a rated power of 24 hp, which positions it at the lighter end of its class. It is equipped with a diesel liquid-cooled engine and four-wheel drive with a hydrostatic transmission. The tractor's listed operating weight is 1065 kg, and it is suitable for operations covering areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1065 kg
Catalogue coverage
Variants represented
2
Richest spec table
22 rows
Recorded power
24 hp
Recorded weight
1065 kg
Transmissions
hydrostatic
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerHitachiReference
Built in JapanReference
Drive4WDReference
Variants
TZ240SHhydrostaticReference
Engine
1.5L dieselReference
Fuel tank28.0 LReference
Engine17.7 kWReference
dieselReference
liquid-cooledReference
Displacement1.5 LReference
Power17.7 kWReference
Rated RPM2500Reference
Dimensions
Weight1065 kgReference
Front tire6-14Reference
Rear tire9.5-24Reference
Ag front6-14Reference
Ag rear9.5-24Reference
Length286 cmReference
Height195 cmReference
Ground clearance33 cmReference
Transmission
TransmissionhydrostaticReference
Gearsinfinite forward and reverseReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
