The Holder A15 is a tractor with a rated output of 12 hp — making it one of the more compact options in its class. Power comes from a 1-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a 6-speed gearbox. Listed weight is 494 kg, and it is aimed at jobs of around up to 200 ac. Available dimensions and performance figures follow in both unit systems.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Weight
494 kg
Catalogue coverage
Variants represented
2
Richest spec table
41 rows
Recorded power
12 hp
Recorded weight
494 kg
Transmissions
6-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerHolderReference
Four-wheel driveReference
Open operator station.Reference
Engine
Holder 0.6L 1-cyl dieselReference
Fuel tank6.4 LReference
Engine8.9 kWReference
Holder HD1Reference
dieselReference
1-cylinderReference
liquid-cooledReference
Displacement0.6 LReference
Bore/Stroke88 x 90 mmReference
Power8.9 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Rated RPM2600Reference
Starter volts12Reference
Oil capacity0.9 LReference
Coolant capacity3.8 LReference
Transmission
6-speedReference
Gears6 forward and 3 reverseReference
Clutchdry discReference
PTO & Hydraulics
Typeopen centerReference
Pump flow5.5 lpmReference
Rear PTO Type540Reference
Engine RPM540@2100Reference
Engine RPM760@2600Reference
Dimensions
Wheelbase93 cmReference
Weight494 kgReference
Front tire6-14Reference
Rear tire6-14Reference
Ag front6-14Reference
Ag rear6-14Reference
Length189 cmReference
Width62 cmReference
Height (hood)93 cmReference
Ground clearance21 cmReference
494 kgReference
Max front axle380 kgReference
Max rear axle380 kgReference
Speeds
With 6-14 tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
