Industrial Tractor · 2010Unverified

Holder C480

Name: Holder C480
Brand: Holder

Holder C480 — C400 Series · 77 hp. Reference specifications; pending source verification.

The Holder C480 is a mid-range industrial tractor with a power rating of approximately 77 hp. Produced in 2010, this model features a 4-cylinder turbocharged diesel air-cooled engine, and four-wheel drive with a hydrostatic transmission. The tractor has an operating weight of 2390 kg and is suitable for use on up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

77 hp

Weight

2390 kg

Catalogue coverage

Variants represented

Richest spec table

51 rows

Recorded power

77 hp

Recorded weight

2390 kg

Transmissions

hydrostatic

Production years

2010-2010

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerHolderReference

Articulated truckReference

Four-wheel driveReference

Differential lockelectro-hydraulic front and rearReference

Steeringhydrostatic powerReference

Hydraulic drum brakesReference

Cab standardReference

Engine

Deutz 3.6L 4-cyl dieselReference

Engine57.4 kWReference

DeutzReference

turbocharged dieselReference

4-cylinderReference

air-cooledReference

Displacement3.6 LReference

Power57.4 kWReference

Air cleanerdry elementReference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverseReference

Capacities

Fuel59.8 LReference

PTO & Hydraulics

Hydraulic system41.6 LReference

Capacity41.6 LReference

Pump flow26.5 lpmReference

Rear TypeIIReference

Rear lift1995 kgReference

Front HitchIIReference

Front lift1995 kgReference

Rear PTO Type540 (optional)Reference

Front PTO Type540Reference

Front PTO Type1000 (optional)Reference

Dimensions

Wheelbase200 cmReference

Weight2390 kgReference

Front tire10.5x80R18Reference

Rear tire10.5x80R18Reference

Ag front31x15.5-50Reference

Ag rear31x15.5-50Reference

Lawn/turf front31x15.5R15Reference

Lawn/turf rear31x15.5R15Reference

Industrial front10.5x80R18Reference

Industrial rear10.5x80R18Reference

Length416 cmReference

Width119 cmReference

Height (cab)228 cmReference

Shipping weight2390 kgReference

Max weight3999 kgReference

Front tread96 to 116 cmReference

Rear tread96 to 116 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
