Tractor · 1919Unverified
Holt 5-Ton
Holt 5-Ton — Agricultural Crawler tractor · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Max power
24.6 kW
Weight
4536 kg
Hover a source tag to verify
Overview
ManufacturerHoltReference
Agricultural Crawler tractorReference
Also known as the Holt T-11 or 25-40.Reference
DrivecrawlerReference
Open operator station.Reference
Engine
Holt 7.0L 4-cyl gasolineReference
Drawbar (tested)24.6 kWReference
Belt (tested)26.8 kWReference
HoltReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement7.0 LReference
Bore/Stroke121 x 152 mmReference
Rated RPM1050Reference
Belt power (max)26.8 kWReference
Max power24.6 kWReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Dimensions
Weight4536 kgReference
TracksReference
Test results
3-speed crawlerAugust 30 - September 17, 1920Link: Nebraska Tractor Test 59 fileReference
Drawbar performanceReference
Max pull2521 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
