The Huber 30-60 is a compact tractor model with a rated output of 30 hp, featuring a 4-cylinder liquid-cooled engine. Manufactured from 1912 to 1916, this model is equipped with a two-wheel drive system and a 2-speed gearbox. The listed weight of the 30-60 is 10523 kg, and it is suitable for tasks on approximately 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
10523 kg
Catalogue coverage
Variants represented
2
Richest spec table
29 rows
Recorded power
30 hp
Recorded weight
10523 kg
Transmissions
2-speed gear
Production years
1912-1916
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerHuberReference
Standard-tread tractorReference
Built in Marion, Ohio, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Huber 21.7L 4-cyl keroseneReference
Fuel tank246.0 LReference
Drawbar (claimed)22.4 kWReference
Belt (claimed)44.7 kWReference
HuberReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement21.7 LReference
Bore/Stroke184 x 203 mmReference
Rated RPM550Reference
Coolant capacity359.6 LReference
Transmission
2-speed gearReference
TypegearReference
Gears2 forward and 1 reverseReference
Dimensions
Weight10523 kgReference
Rear tire96x30Reference
Ag rear96x30 (steel)Reference
Length645 cmReference
Width294 cmReference
Height269 cmReference
Capacities
Diameter60 cmReference
Width30 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
