Tractor · 1912Unverified
Huber 30-60
Huber 30-60 — Standard-tread tractor · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
10523 kg
Hover a source tag to verify
Overview
ManufacturerHuberReference
Standard-tread tractorReference
Built in Marion, Ohio, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Huber 21.7L 4-cyl keroseneReference
Fuel tank246.0 LReference
Drawbar (claimed)22.4 kWReference
Belt (claimed)44.7 kWReference
HuberReference
keroseneReference
4-cylinderReference
liquid-cooledReference
Displacement21.7 LReference
Bore/Stroke184 x 203 mmReference
Rated RPM550Reference
Coolant capacity359.6 LReference
Transmission
2-speed gearReference
TypegearReference
Gears2 forward and 1 reverseReference
Dimensions
Weight10523 kgReference
Rear tire96x30Reference
Ag rear96x30 (steel)Reference
Length645 cmReference
Width294 cmReference
Height269 cmReference
Capacities
Diameter60 cmReference
Width30 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
