Tractor · 1927Unverified

Huber 40-62

Name: Huber 40-62
Brand: Huber

Huber 40-62 — Standard-tread tractor · 40 hp. Reference specifications; pending source verification.

The Huber 40-62 is a tractor model rated at approximately 40 hp, positioned towards the lower end of its class. It was manufactured from 1927 to 1941. The model features a 4-cylinder petrol liquid-cooled engine, coupled with two-wheel drive and a 2-speed gearbox. Its operating weight is listed at 4427 kg, with a maximum suitable operational area of 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

40 hp

Max power

37.3 kW

Weight

4427 kg

Catalogue coverage

Variants represented

Richest spec table

45 rows

Recorded power

40 hp

Recorded weight

4427 kg

Transmissions

2-speed gear

Production years

1927-1941

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerHuberReference

Standard-tread tractorReference

Built in Marion, Ohio, USAReference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Engine

Stearns 10.1L 4-cyl gasolineReference

Fuel tank208.2 LReference

Drawbar (claimed)29.8 kWReference

Belt (claimed)46.2 kWReference

Plows6Reference

Drawbar (tested)37.3 kWReference

Belt (tested)52.0 kWReference

StearnsReference

gasolineReference

4-cylinderReference

liquid-cooledReference

Displacement10.1 LReference

Bore/Stroke140 x 165 mmReference

Air cleaneroil sprayReference

Rated RPM1100Reference

Coolant capacity43.5 LReference

Belt power (max)52.0 kWReference

Max power37.3 kWReference

Transmission

2-speed gearReference

TypegearReference

Gears2 forward and 1 reverseReference

Clutchdry discReference

Dimensions

Wheelbase241 cmReference

Weight4427 kgReference

Front tire40x7Reference

Rear tire56x20Reference

Ag front40x7 (steel)Reference

Ag rear56x20 (steel)Reference

Length406 cmReference

Width223 cmReference

Height (hood)157 cmReference

Operating weight4427 kgReference

Capacities

Diameter39 cmReference

Width23 cmReference

RPM666Reference

Test results

Gasoline 2WDMay 17 - June 24, 1927Link: Nebraska Tractor Test 135 fileReference

Belt fuel use (max)30.7 l/hourReference

Drawbar performanceReference

Max pull3450 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
