Tractor · 1936Unverified
Huber B
Huber B — Row-Crop tractor · 23 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
23 hp
Max power
17.1 kW
Weight
1957 kg
Hover a source tag to verify
Overview
ManufacturerHuberReference
Row-Crop tractorReference
Built in Marion, Ohio, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
Brow-cropReference
OBorchardReference
Engine
Buda 3.4L 4-cyl gasolineReference
Plows2Reference
Drawbar (tested)17.1 kWReference
Belt (tested)20.5 kWReference
BudaReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Bore/Stroke97 x 114 mmReference
Air cleaneroil bathReference
Rated RPM1300Reference
Belt power (max)20.5 kWReference
Max power17.1 kWReference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
Dimensions
Weight1957 kgReference
Operating weight1957 kgReference
Capacities
Diameter25 cmReference
Width18 cmReference
RPM990Reference
Speed797.66 meters/minReference
Test results
Gasoline 2WDOctober 13 - November 8, 1937Link: Nebraska Tractor Test 292 fileReference
Belt fuel use (max)11.4 l/hourReference
Drawbar performanceReference
Gear 4 used for power test.Reference
Max pull1255 kgReference
Gear 2 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
