Tractor · 1936Unverified
Huber LC
Huber LC — Modern Farmer Series · 31 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
31 hp
Max power
23.4 kW
Weight
1769 kg
Hover a source tag to verify
Overview
ManufacturerHuberReference
Row-Crop tractorReference
Built in Marion, Ohio, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
LstandardReference
LCrow-cropReference
Engine
Waukesha 5.5L 4-cyl gasolineReference
Plows3Reference
Drawbar (tested)23.4 kWReference
Belt (tested)32.2 kWReference
Waukesha VIKReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement5.5 LReference
Bore/Stroke114 x 133 mmReference
Air cleaneroil bathReference
Rated RPM1200Reference
Belt power (max)32.2 kWReference
Max power23.4 kWReference
Transmission
3-speed gearReference
TypegearReference
Gears3 forward and 1 reverseReference
Dimensions
Weight1769 kgReference
Length330 cmReference
Width207 cmReference
Height144 cmReference
Capacities
Diameter43 cmReference
Width18 cmReference
RPM705Reference
Speed792.48 meters/minReference
Test results
Gasoline 2WDOctober 11 - 28, 1937Link: Nebraska Tractor Test 291 fileReference
Belt fuel use (max)15.1 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull1809 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
