The Hurlimann D 500 is a tractor with a rated power output of 65 hp, a mid-range figure for its class. It was manufactured from 1947 to 1956 and features a 4-cylinder diesel liquid-cooled engine paired with two-wheel drive and a 5-speed gearbox. The operating weight of the tractor is 3500 kg, and it is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
3500 kg
Catalogue coverage
Variants represented
2
Richest spec table
35 rows
Recorded power
65 hp
Recorded weight
3500 kg
Transmissions
5-speed gear
Production years
1947-1956
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerHurlimannReference
Built in Wil, SwitzerlandReference
Total built65Reference
Two-wheel driveReference
Differential lockmechanical rearReference
Cab standard.Reference
Engine
Hurlimann 5.5L 4-cyl dieselReference
Fuel tank50.0 LReference
Engine48.5 kWReference
Hurlimann D-300Reference
dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement5.5 LReference
Bore/Stroke112 x 140 mmReference
Power48.5 kWReference
Fuel systemdirect injectionReference
Air cleaneroil bathReference
Compression18:1Reference
Rated RPM1600Reference
StarterelectricReference
Starter volts24Reference
Transmission
5-speed gearReference
TypegearReference
Gears5 forward and 1 reverseReference
Clutchmechanical dry discReference
Dimensions
Wheelbase202 cmReference
Weight3500 kgReference
Front tire6.00-20Reference
Rear tire13.00-24Reference
Ag front6.00-20Reference
Ag rear13.00-24Reference
Length325 cmReference
Width175 cmReference
Height215 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
