Tractor · 1998Unverified

Hurlimann H-1200 SX

Name: Hurlimann H-1200 SX
Brand: Hurlimann

Hurlimann H-1200 SX · 120 hp. Reference specifications; pending source verification.

The Hurlimann H-1200 SX is a high-powered tractor, rated at 120 hp, positioned towards the upper end of its class. Manufactured from 1998 to 2004, the H-1200 SX is equipped with a 6-cylinder diesel engine, delivering mechanical front-wheel drive via a hydrostatic transmission. Weighing 6100 kg, this tractor is designed for applications involving approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

120 hp

Weight

6100 kg

Catalogue coverage

Variants represented

Richest spec table

29 rows

Recorded power

120 hp

Recorded weight

6100 kg

Transmissions

18-speed

Production years

1998-2004

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerHurlimannReference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD optionalReference

Steeringhydrostatic powerReference

Engine

SAME 6.0L 6-cyl dieselReference

Fuel tank380.0 LReference

Engine89.5 kWReference

SAMEReference

dieselReference

6-cylinderReference

Displacement6.0 LReference

Bore/Stroke105 x 115 mmReference

Power89.5 kWReference

Rated RPM2350Reference

Torque524.1 NmReference

Torque RPM1450Reference

Transmission

18-speedReference

Gears18 forward and reverseReference

PTO & Hydraulics

Pump flow103.0 lpmReference

Rear lift8601 kgReference

Rear PTO Type540, 1000Reference

Dimensions

Wheelbase275 cmReference

Weight6100 kgReference

Front tire16.9R28Reference

Rear tire18.4R38Reference

Ag front16.9R28Reference

Ag rear18.4R38Reference

Length467 cmReference

Height288 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
