Tractor · 2000Unverified

Hurlimann H-1600 SX

Name: Hurlimann H-1600 SX
Brand: Hurlimann

Hurlimann H-1600 SX · 160 hp. Reference specifications; pending source verification.

The Hurlimann H-1600 SX is a tractor model rated at 160 horsepower, positioning it among higher-powered machines in its class. It was produced from 2000 to 2004. It features a 6-cylinder diesel engine, coupled with a mechanical front-wheel drive system and a hydrostatic transmission. The listed weight is 6801 kg, and it is suited for tasks involving approximately 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

160 hp

Weight

6801 kg

Catalogue coverage

Variants represented

Richest spec table

28 rows

Recorded power

160 hp

Recorded weight

6801 kg

Transmissions

18-speed

Production years

2000-2004

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerHurlimannReference

Drive4x2 2WDReference

Drive4x4 MFWD 4WD optionalReference

Steeringhydrostatic powerReference

Engine

SAME 6.0L 6-cyl dieselReference

Fuel tank400.1 LReference

Engine119.3 kWReference

SAMEReference

dieselReference

6-cylinderReference

Displacement6.0 LReference

Bore/Stroke105 x 115 mmReference

Power119.3 kWReference

Rated RPM2350Reference

Torque705.1 NmReference

Torque RPM1400Reference

Transmission

18-speedReference

Gears18 forward and reverseReference

PTO & Hydraulics

Pump flow113.2 lpmReference

Rear lift10001 kgReference

Rear PTO Type540, 1000Reference

Dimensions

Wheelbase284 cmReference

Weight6801 kgReference

Front tire540/65R30Reference

Rear tire650/65R38Reference

Ag front540/65R30Reference

Ag rear650/65R38Reference

Height296 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
