The Hurlimann H-1800 SX is a tractor model with a rated power of 180 hp, placing it at the more powerful end of its class. This model was produced between 2000 and 2004. It features a 6-cylinder diesel engine, paired with mechanical front-wheel drive and a hydrostatic transmission. The H-1800 SX has a listed operating weight of 7101 kg and is suitable for operations of up to 1,500 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
180 hp
Weight
7101 kg
Catalogue coverage
Variants represented
2
Richest spec table
28 rows
Recorded power
180 hp
Recorded weight
7101 kg
Transmissions
18-speed
Production years
2000-2004
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerHurlimannReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringhydrostatic powerReference
Engine
SAME 6.0L 6-cyl dieselReference
Fuel tank400.1 LReference
Engine134.2 kWReference
SAMEReference
dieselReference
6-cylinderReference
Displacement6.0 LReference
Bore/Stroke105 x 115 mmReference
Power134.2 kWReference
Rated RPM2350Reference
Torque780.1 NmReference
Torque RPM1400Reference
Transmission
18-speedReference
Gears18 forward and reverseReference
PTO & Hydraulics
Pump flow113.2 lpmReference
Rear lift10001 kgReference
Rear PTO Type750, 1000Reference
Dimensions
Wheelbase284 cmReference
Weight7101 kgReference
Front tire480/70R34Reference
Rear tire580/70R42Reference
Ag front480/70R34Reference
Ag rear580/70R42Reference
Height296 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
