Tractor · 1993Unverified

Hurlimann H-305 XE

Name: Hurlimann H-305 XE
Brand: Hurlimann

Hurlimann H-305 XE — H-300 XE Series · 50 hp. Reference specifications; pending source verification.

The Hurlimann H-305 XE is a tractor with a rated power output of 50 hp, positioned at the lighter end of its class. It was in production from 1993 to 2001. The tractor is equipped with a 3-cylinder diesel air-cooled engine, paired with four-wheel drive and an 8-speed gearbox. Its operating weight is listed as 4277 to 4740 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

50 hp

Weight

4277 to 4740 pounds

Catalogue coverage

Variants represented

Richest spec table

64 rows

Recorded power

50 hp

Recorded weight

1940 kg

Transmissions

8-speed mechanical shuttle

Production years

1993-2001

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerHurlimann (a part of SAME)Reference

Utility tractorReference

Two- or four-wheel driveReference

Final drivesplanetaryReference

Power steeringReference

Hydraulic wet disc brakesReference

Trailer brakeshydraulicReference

Four-post ROPS.Reference

Engine

SAME 3.0L 3-cyl dieselReference

Fuel tank57.9 LReference

Engine37.0 kWReference

SAME 1000.3 AReference

dieselReference

3-cylinderReference

air-cooledReference

Displacement3.0 LReference

Bore/Stroke105 x 115 mmReference

Power37.0 kWReference

Rated RPM2350Reference

Starter volts12Reference

Transmission

8-speed mechanical shuttleReference

12-speed creeperReference

16-speedReference

24-speed creeperReference

Typemechanical shuttleReference

Gears8 forward and reverseReference

TypecreeperReference

Gears12 forward and reverseReference

Gears16 forward and 8 reverseReference

Gears24 forward and 12 reverseReference

PTO & Hydraulics

Valves2 or 3Reference

Pump flow32.9 lpmReference

Rear TypeIIReference

Rear lift2960 kgReference

Rear PTOindependentReference

Rear PTO Type540/540EReference

Rear PTO Type540/1000Reference

Rear PTO Type1000Reference

Dimensions

2WD Wheelbase197 cmReference

4WD Wheelbase192 cmReference

Weight4277 to 4740 poundsReference

Front tire6.50-16Reference

2WD Rear tire380/70R28Reference

2WD Standard tires (ag)Front: 6.50-16. Rear: 380/70R28Reference

4WD Standard tires (ag)Front: 300/70R20. Rear: 380/70R28Reference

2WD Optional tires (ag)Front: 6.00-19. Rear: 12.4R32Reference

2WD Optional tires (ag)Front: 7.50-16. Rear: 420/70R28Reference

4WD Optional tires (ag)Front: 8.3R24. Rear: 12.4R32Reference

4WD Optional tires (ag)Front: 320/70R20. Rear: 420/70R28Reference

Length338 cmReference

Width164 cmReference

2WD Weight1940 kgReference

4WD Weight2150 kgReference

2WD Ground clearance39 cmReference

4WD Ground clearance33 cmReference

2WD Front tread122 to 152 cmReference

4WD Front tread134 to 173 cmReference

Rear tread130 to 169 cmReference

Steering wheel149 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Hurlimann H-305 XE Height

Hood135 cmReference

ROPS224 cmReference

Speeds

With 420/70R30 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
