Tractor · 1993Unverified

Hurlimann H-307 XE

Name: Hurlimann H-307 XE
Brand: Hurlimann

Hurlimann H-307 XE — H-300 XE Series · 69 hp. Reference specifications; pending source verification.

The Hurlimann H-307 XE is a tractor with a rated output of 69 horsepower, placing it in the middle of its class for power. Produced from 1993 to 2001, this model features a 3-cylinder turbocharged diesel air-cooled engine, which is coupled to an 8-speed gearbox and powers four-wheel drive. The listed weight of the tractor is 4564 to 5115 pounds. It is designed for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

69 hp

Weight

4564 to 5115 pounds

Catalogue coverage

Variants represented

Richest spec table

64 rows

Recorded power

69 hp

Recorded weight

2070 kg

Transmissions

8-speed mechanical shuttle

Production years

1993-2001

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerHurlimann (a part of SAME)Reference

Utility tractorReference

Two- or four-wheel driveReference

Final drivesplanetaryReference

Power steeringReference

Hydraulic wet disc brakesReference

Trailer brakeshydraulicReference

Four-post ROPS.Reference

Engine

SAME 3.0L 3-cyl dieselReference

Fuel tank57.9 LReference

Engine51.5 kWReference

SAME 1000.3 AReference

turbocharged dieselReference

3-cylinderReference

air-cooledReference

Displacement3.0 LReference

Bore/Stroke105 x 115 mmReference

Power51.5 kWReference

Rated RPM2350Reference

Starter volts12Reference

Transmission

8-speed mechanical shuttleReference

12-speed creeperReference

16-speedReference

24-speed creeperReference

Typemechanical shuttleReference

Gears8 forward and reverseReference

TypecreeperReference

Gears12 forward and reverseReference

Gears16 forward and 8 reverseReference

Gears24 forward and 12 reverseReference

PTO & Hydraulics

Valves2 or 3Reference

Pump flow32.9 lpmReference

Rear TypeIIReference

Rear lift2960 kgReference

Rear PTOindependentReference

Rear PTO Type540/540EReference

Rear PTO Type540/1000Reference

Rear PTO Type1000Reference

Dimensions

2WD Wheelbase210 cmReference

4WD Wheelbase205 cmReference

Weight4564 to 5115 poundsReference

Front tire7.50-16Reference

2WD Rear tire420/70R30Reference

2WD Standard tires (ag)Front: 7.50-16. Rear: 420/70R30Reference

4WD Standard tires (ag)Front: 360/70R20. Rear: 420/70R30Reference

2WD Optional tires (ag)Front: 6.50-20. Rear: 12.4R36Reference

2WD Optional tires (ag)Front: 7.50-18. Rear: 16.9R30Reference

4WD Optional tires (ag)Front: 11.2R24. Rear: 12.4R36Reference

4WD Optional tires (ag)Front: 11.2R24. Rear: 16.9R30Reference

Length358 cmReference

Width178 cmReference

2WD Weight2070 kgReference

4WD Weight2320 kgReference

2WD Ground clearance44 cmReference

4WD Ground clearance38 cmReference

2WD Front tread127 to 156 cmReference

4WD Front tread144 to 173 cmReference

Rear tread139 to 180 cmReference

Steering wheel156 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Hurlimann H-307 XE Height

Hood142 cmReference

ROPS230 cmReference

Speeds

With 420/70R30 rear tires.Reference
