The Hurlimann H-466 is a tractor with an approximate engine power of 65 hp, falling within the mid-range of its class. It was manufactured from 1983 to 1986. The H-466 features a 4-cylinder diesel engine, coupled with a four-wheel drive system and a 24-speed gearbox. Its operating weight is listed as 6218-6592 pounds, suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
6218 to 6592 pounds
Catalogue coverage
Variants represented
2
Richest spec table
31 rows
Recorded power
65 hp
Recorded weight
2820 kg
Transmissions
24-speed
Production years
1983-1986
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerHurlimannReference
Two- or four-wheel driveReference
Power steeringReference
Engine
SAME 3.7L 4-cyl dieselReference
Fuel tank70.0 LReference
Engine48.5 kWReference
SAMEReference
dieselReference
4-cylinderReference
Displacement3.7 LReference
Bore/Stroke103 x 110 mmReference
Power48.5 kWReference
Rated RPM2350Reference
Torque236.1 NmReference
Torque RPM1300Reference
Transmission
24-speedReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
Pump flow34.8 lpmReference
Rear lift3430 kgReference
Rear PTO Type540, 1000Reference
Dimensions
Wheelbase235 cmReference
Weight6218 to 6592 poundsReference
Front tire7.50-16Reference
Rear tire16.9-30Reference
Ag front7.50-16Reference
Ag front12.4-24 (4WD)Reference
Ag rear16.9-30Reference
Length402 cmReference
Height248 cmReference
Weight2820 kgReference
Weight2990 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
