Tractor · 1989Unverified
Hurlimann H-468 Prestige
Hurlimann H-468 Prestige — Model year 1989-19981998-2003 · 69 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
69 hp
Weight
5798 to 6768 pounds
Hover a source tag to verify
Overview
ManufacturerHurlimannReference
Two- or four-wheel driveReference
Power steeringReference
Four-post ROPS. Cab optional.Reference
Variants
Grand Prix 674-70similar Lamborghini modelReference
Engine
SAME 4.0L 4-cyl dieselReference
Fuel tank90.1 LReference
Engine51.5 kWReference
SAME 1000.4WReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke105 x 116 mmReference
Power51.5 kWReference
Rated RPM2350Reference
Torque259.0 NmReference
Torque RPM1250Reference
Starter volts12Reference
Transmission
12-speedReference
20-speedReference
30-speedReference
Gears12 forward and reverseReference
Gears20 forward and reverseReference
TransmissionDrive PowerReference
Gears30 forward and reverseReference
PTO & Hydraulics
Typeload sensingReference
Pump flow36.0 lpmReference
Rear TypeIIReference
Rear lift3430 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2083Reference
Engine RPM540E@1743Reference
Engine RPM1000@2286Reference
Engine RPM1000E@1913Reference
Dimensions
2WD Wheelbase235 cmReference
4WD Wheelbase228 cmReference
Weight5798 to 6768 poundsReference
Front tire7.50-16Reference
2WD Rear tire16.9/14-30Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 16.9/14-30Reference
4WD Standard tires (ag)Front: 12.4/11-24. Rear: 16.9/14-30Reference
2WD Optional tires (ag)Front: 7.50-20. Rear: 13.6/12-38Reference
4WD Optional tires (ag)Front: 12.4/11-28. Rear: 13.6/12-38Reference
4WD Optional tires (ag)Front: 14.9/13-24. Rear: 16.9/14-34Reference
2WD Length363 cmReference
4WD Length373 cmReference
Width197 cmReference
2WD Ground clearance49 cmReference
4WD Ground clearance40 cmReference
2WD ROPS2629 kgReference
2WD Cab2830 kgReference
4WD ROPS2869 kgReference
4WD Cab3069 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Hurlimann H-468 Prestige Height
Hood156 cmReference
ROPS244 cmReference
Cab249 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
