Tractor · 1979Unverified
Hurlimann H-480
Hurlimann H-480 — H-400 Series · 81 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
81 hp
Weight
6768 to 7275 pounds
Hover a source tag to verify
Overview
ManufacturerHurlimann (a part of SAME)Reference
Built in Wil, SwitzerlandReference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic disc brakesReference
Cab standard.Reference
Engine
Hurlimann 4.6L 4-cyl dieselReference
Fuel tank95.0 LReference
Engine60.0 kWReference
Hurlimann H-1104Reference
dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement4.6 LReference
Bore/Stroke110 x 120 mmReference
Power60.0 kWReference
Compression16:1Reference
Rated RPM2300Reference
Torque315.0 NmReference
Torque RPM1200Reference
Starter typeelectricReference
Coolant capacity16.0 LReference
Transmission
12-speed synchronizedReference
16-speed creeperReference
TypesynchronizedReference
Gears12 forward and 3 reverseReference
TypecreeperReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
Rear TypeIIReference
Rear lift2200 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase233 cmReference
Weight6768 to 7275 poundsReference
Front tire7.50-18Reference
2WD Rear tire16.9-34Reference
2WD Standard tires (ag)Front: 7.50-18. Rear: 16.9-34Reference
4WD Standard tires (ag)Front: 13.6-24. Rear: 16.9-34Reference
2WD Optional tires (ag)Front: 7.50-18. Rear: 18.4-30Reference
2WD Optional tires (ag)Front: 7.50-18. Rear: 13.6-38Reference
4WD Optional tires (ag)Front: 12.4-24. Rear: 18.4-30Reference
4WD Optional tires (ag)Front: 12.4-24. Rear: 13.6-38Reference
2WD Length399 cmReference
4WD Length421 cmReference
Width208 cmReference
Height (cab)272 cmReference
2WD Weight3069 kgReference
4WD Weight3299 kgReference
Ground clearance41 cmReference
2WD Front tread139 to 189 cmReference
4WD Front tread169 to 198 cmReference
Rear tread162 to 221 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
