The Hurlimann H-488T is a tractor model with a rated power output of 88 hp, a mid-range figure for its class. It was manufactured between 1986 and 1990, and is equipped with a 4-cylinder turbocharged diesel liquid-cooled engine, which is paired with a 20-speed gearbox and four-wheel drive. The tractor has a listed operating weight of 3495 kg and is suitable for operations up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
88 hp
Weight
3495 kg
Catalogue coverage
Variants represented
2
Richest spec table
29 rows
Recorded power
88 hp
Recorded weight
3495 kg
Transmissions
20-speed
Production years
1986-1990
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerHurlimannReference
Two- or four-wheel driveReference
Power steeringReference
Engine
SAME 4.0L 4-cyl dieselReference
Fuel tank99.9 LReference
Engine65.6 kWReference
SAME 1000.4WTReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke105 x 116 mmReference
Power65.6 kWReference
Rated RPM2500Reference
Torque323.0 NmReference
Torque RPM1300Reference
Transmission
20-speedReference
Gears20 forward and reverseReference
PTO & Hydraulics
Pump flow42.4 lpmReference
Rear lift3430 kgReference
Rear PTO Type540, 1000Reference
Dimensions
Wheelbase232 cmReference
Weight3495 kgReference
Front tire13.6-28Reference
Rear tire18.4-34Reference
Ag front13.6-28Reference
Ag rear18.4-34Reference
Length408 cmReference
Height262 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
