Tractor · 1991Unverified

Hurlimann H-6165 Master

Name: Hurlimann H-6165 Master
Brand: Hurlimann

Hurlimann H-6165 Master — Master Series · 163 hp. Reference specifications; pending source verification.

The Hurlimann H-6165 Master is a tractor with a rated power output of 163 hp, positioning it among the higher-powered machines in its class. Manufactured from 1991 to 2001, the H-6165 Master features a 6-cylinder turbocharged diesel liquid-cooled engine, coupled with a powershift transmission and four-wheel drive. Its listed weight is 5830 kg, making it suitable for tasks involving around 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

163 hp

Weight

5830 kg

Catalogue coverage

Variants represented

Richest spec table

49 rows

Recorded power

163 hp

Recorded weight

5830 kg

Transmissions

27-speed 9-speed power shift

Production years

1991-2001

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerHurlimannReference

Row-Crop tractorReference

Four-wheel driveReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard with air-conditioning.Reference

Variants

165 Racingsimilar Lamborghini modelReference

Engine

SAME 6.0L 6-cyl dieselReference

Fuel tank360.0 LReference

Engine121.5 kWReference

SAME 1000.6Reference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.0 LReference

Bore/Stroke105 x 116 mmReference

Power121.5 kWReference

Rated RPM2350Reference

Torque607.1 NmReference

Torque RPM1400Reference

Starter typeelectricReference

Transmission

27-speed 9-speed power shiftReference

Type9-speed power shiftReference

Gears27 forward and reverseReference

Clutchelectro-hydraulic wet discReference

Nine power shift gears in three ranges. Synchronized shuttle.Reference

PTO & Hydraulics

Pump flow60.2 lpmReference

Rear lift6999 kgReference

Rear lift8601 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type540/1000Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

Wheelbase284 cmReference

Weight5830 kgReference

Front tire16.9R30Reference

Rear tire20.8R38Reference

Standard tires (ag)Front: 16.9R30. Rear: 20.8R38Reference

Optional tires (ag)Front: 480/70R30. Rear: 580/70R38Reference

Length451 cmReference

Length474 cmReference

Width235 cmReference

Height (hood)192 cmReference

Height (cab)290 cmReference

Ground clearance51 cmReference

Front tread189 to 249 cmReference

Rear tread183 to 255 cmReference

Speeds

With 20.8R38 rear tires and 40 KPH transmission option. Reverse speeds are 9% faster than forward.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
