Tractor · 1992Unverified
Hurlimann H-6190 Master
Hurlimann H-6190 Master — Master Series · 189 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
189 hp
Weight
6000 kg
Hover a source tag to verify
Overview
ManufacturerHurlimannReference
Row-Crop tractorReference
Four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
190 Racingsimilar Lamborghini modelReference
Engine
SAME 6.0L 6-cyl dieselReference
Fuel tank230.1 LReference
Fuel tank360.0 LReference
Engine140.9 kWReference
SAME 1000.6Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.0 LReference
Bore/Stroke105 x 116 mmReference
Power140.9 kWReference
Rated RPM2350Reference
Torque656.2 NmReference
Torque RPM1350Reference
Starter typeelectricReference
Transmission
27-speed 9-speed power shiftReference
Type9-speed power shiftReference
Gears27 forward and reverseReference
Clutchelectro-hydraulic wet discReference
Nine power shift gears in three ranges. Synchronized shuttle.Reference
PTO & Hydraulics
Pump flow60.2 lpmReference
Rear lift8601 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type1000Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
Wheelbase284 cmReference
Weight6000 kgReference
Front tire16.9R30Reference
Rear tire20.8R38Reference
Standard tires (ag)Front: 16.9R30. Rear: 20.8R38Reference
Optional tires (ag)Front: 480/70R30. Rear: 580/70R38Reference
Optional tires (ag)Front: 480/70R30. Rear: 650/75R34Reference
Length451 cmReference
Length474 cmReference
Width235 cmReference
Height (hood)192 cmReference
Height (cab)290 cmReference
Ground clearance51 cmReference
Front tread189 to 249 cmReference
Rear tread183 to 255 cmReference
Speeds
With 20.8R38 rear tires and 40 KPH transmission option. Reverse speeds are 9% faster than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
