Tractor · 1992Unverified

Hurlimann H-6190 Master

Name: Hurlimann H-6190 Master
Brand: Hurlimann

Hurlimann H-6190 Master — Master Series · 189 hp. Reference specifications; pending source verification.

The Hurlimann H-6190 Master is a tractor with a rated output of 189 horsepower, situated among the higher-powered models in its class. Manufactured between 1992 and 2001, this tractor is equipped with a 6-cylinder turbocharged diesel liquid-cooled engine, transmitting power through a four-wheel drive system with a powershift transmission. The listed weight of the H-6190 Master is 6000 kilograms, and it is suited to tasks involving land areas of approximately 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

189 hp

Weight

6000 kg

Catalogue coverage

Variants represented

Richest spec table

50 rows

Recorded power

189 hp

Recorded weight

6000 kg

Transmissions

27-speed 9-speed power shift

Production years

1992-2001

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerHurlimannReference

Row-Crop tractorReference

Four-wheel driveReference

Power steeringReference

Hydraulic wet disc brakesReference

Cab standard with air-conditioning.Reference

Variants

190 Racingsimilar Lamborghini modelReference

Engine

SAME 6.0L 6-cyl dieselReference

Fuel tank230.1 LReference

Fuel tank360.0 LReference

Engine140.9 kWReference

SAME 1000.6Reference

turbocharged dieselReference

6-cylinderReference

liquid-cooledReference

Displacement6.0 LReference

Bore/Stroke105 x 116 mmReference

Power140.9 kWReference

Rated RPM2350Reference

Torque656.2 NmReference

Torque RPM1350Reference

Starter typeelectricReference

Transmission

27-speed 9-speed power shiftReference

Type9-speed power shiftReference

Gears27 forward and reverseReference

Clutchelectro-hydraulic wet discReference

Nine power shift gears in three ranges. Synchronized shuttle.Reference

PTO & Hydraulics

Pump flow60.2 lpmReference

Rear lift8601 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulic wet discReference

Rear PTO Type1000Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

Wheelbase284 cmReference

Weight6000 kgReference

Front tire16.9R30Reference

Rear tire20.8R38Reference

Standard tires (ag)Front: 16.9R30. Rear: 20.8R38Reference

Optional tires (ag)Front: 480/70R30. Rear: 580/70R38Reference

Optional tires (ag)Front: 480/70R30. Rear: 650/75R34Reference

Length451 cmReference

Length474 cmReference

Width235 cmReference

Height (hood)192 cmReference

Height (cab)290 cmReference

Ground clearance51 cmReference

Front tread189 to 249 cmReference

Rear tread183 to 255 cmReference

Speeds

With 20.8R38 rear tires and 40 KPH transmission option. Reverse speeds are 9% faster than forward.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
