Tractor · 2000Unverified
Hurlimann H-658 XA
Hurlimann H-658 XA — XA Series · 83 hp. Reference specifications; pending source verification.
The Hurlimann H-658 XA is a tractor model with an approximate rating of 83 hp, a mid-range power output for its class. It was manufactured from 2000 to 2004. The tractor features a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive and a 20-speed gearbox. Its operating weight ranges from 5865 to 6372 pounds and is suitable for use on up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
83 hp
Weight
5865 to 6372 pounds
Catalogue coverage
Variants represented
2
Richest spec table
42 rows
Recorded power
83 hp
Recorded weight
2660 kg
Transmissions
20-speed
Production years
2000-2004
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerHurlimann (a part of SAME)Reference
Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Variants
Sprint 684-85similar Lamborghini modelReference
Engine
SAME 4.0L 4-cyl dieselReference
Fuel tank90.1 LReference
Engine61.9 kWReference
SAMEReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke105 x 116 mmReference
Power61.9 kWReference
Rated RPM2350Reference
Torque310.1 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
20-speedReference
30-speedReference
Gears20 forward and 10 reverseReference
Gears30 forward and 15 reverseReference
PTO & Hydraulics
Pump flow36.0 lpmReference
Rear lift3600 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase224 cmReference
Weight5865 to 6372 poundsReference
Front tire7.50-18Reference
Rear tire480/70R30Reference
Ag front7.50-18Reference
Ag front320/70R24 (4WD)Reference
Ag rear480/70R30Reference
Length385 cmReference
Height244 cmReference
Weight2660 kgReference
Weight2890 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
