Tractor · 1999Unverified

Hurlimann Prince 325

Name: Hurlimann Prince 325
Brand: Hurlimann

Hurlimann Prince 325 — Prince Series · 19 hp. Reference specifications; pending source verification.

The Hurlimann Prince 325 is a tractor with a rated power of 19 hp, situated at the lighter end of its class. It was manufactured from 1999 to 2003 and features a 3-cylinder diesel liquid-cooled engine. The Prince 325 is equipped with four-wheel drive, a hydrostatic transmission, and a listed operating weight of 1004 kg, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

19 hp

Weight

1004 kg

Catalogue coverage

Variants represented

Richest spec table

54 rows

Recorded power

19 hp

Recorded weight

1004 kg

Transmissions

12-speed synchronized shuttle

Production years

1999-2003

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerHurlimannReference

Compact Utility tractorReference

Original price$16,000 (1999)Reference

Four-wheel driveReference

Steeringhydrostatic powerReference

Mechanical wet disc brakesReference

Two-post ROPS. Cab optional.Reference

Engine

Mitsubishi 1.1L 3-cyl dieselReference

Fuel tank29.1 LReference

Engine18.6 kWReference

Mitsubishi K3F-DReference

dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.1 LReference

Bore/Stroke78 x 78 mmReference

Power18.6 kWReference

Fuel systemdirect injectionReference

Air cleanerdryReference

Rated RPM3000Reference

Starter volts12Reference

Transmission

12-speed synchronized shuttleReference

Typesynchronized shuttleReference

Gears12 forward and reverseReference

Four gears (1-4) in three ranges with reverser.Reference

PTO & Hydraulics

PTO (claimed)13.8 kWReference

Valves1 (4 optional)Reference

Pump flow22.0 lpmReference

Rear Type1Reference

Controlposition and draft controlReference

Rear lift1199 kgReference

Front Hitch1 (optional)Reference

Front lift400 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Mid PTOoptionalReference

Front PTOoptionalReference

Dimensions

Wheelbase154 cmReference

Weight1004 kgReference

Front tire6.50/80-12Reference

Rear tire250/80-18Reference

Ag front6.50/80-12Reference

Ag rear250/80-18Reference

Length269 cmReference

Width112 cmReference

Width128 cmReference

Ground clearance29 cmReference

Front tread82 to 104 cmReference

Rear tread81 to 101 cmReference

Steering wheel122 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Hurlimann Prince 325 Height

Hood113 cmReference

Cab200 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
