Tractor · 1995Unverified
Hurlimann XA 606
Hurlimann XA 606 — XA Series · 60 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
60 hp
Weight
5291 to 5997 pounds
Hover a source tag to verify
Overview
ManufacturerHurlimann (a part of SAME)Reference
Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with available air-conditioning.Reference
Variants
Sprint 664-60similar Lamborghini modelReference
Engine
SAME 3.0L 3-cyl dieselReference
Fuel tank90.1 LReference
Engine44.7 kWReference
SAME 1000.3W1Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Bore/Stroke105 x 116 mmReference
Power44.7 kWReference
Rated RPM2350Reference
Torque205.0 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
45-speed three-speed power shiftReference
20-speedReference
30-speedReference
TransmissionFulldriveReference
Typethree-speed power shiftReference
Gears45 forward and reverseReference
Five synchronized gears in three ranges with three-speed power shift and shuttle.Reference
Gears20 forward and 10 reverseReference
Gears30 forward and 15 reverseReference
PTO & Hydraulics
Pump flow48.1 lpmReference
Rear TypeIIIReference
Rear lift1860 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
2WD Wheelbase210 cmReference
4WD Wheelbase205 cmReference
Weight5291 to 5997 poundsReference
Front tire7.50-16Reference
2WD Rear tire420/70R28Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 420/70R28Reference
4WD Standard tires (ag)Front: 320/70R20. Rear: 420/70R28Reference
2WD Optional tires (ag)Front: 7.50-16. Rear: 420/70R30Reference
2WD Optional tires (ag)Front: 6.50-20. Rear: 12.4-36Reference
4WD Optional tires (ag)Front: 360/70R20. Rear: 420/70R30Reference
4WD Optional tires (ag)Front: 12.4R20. Rear: 14.9R30Reference
4WD Optional tires (ag)Front: 11.2R24. Rear: 12.4R36Reference
Length372 cmReference
Width192 cmReference
2WD Ground clearance44 cmReference
4WD Ground clearance35 cmReference
2WD Front tread130 to 180 cmReference
4WD Front tread144 to 173 cmReference
Rear tread150 to 189 cmReference
2WD ROPS2399 kgReference
2WD Cab2570 kgReference
4WD ROPS2550 kgReference
4WD Cab2720 kgReference
Steering wheel169 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Hurlimann XA 606 Height
Hood149 cmReference
ROPS237 cmReference
Cab240 cmReference
Speeds
With 420/70R30 rear tires. Reverse speeds are 10% slower than forward. Power shift speeds are 20% faster and slower.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
