Lawn Tractor · 2010Unverified
Husqvarna LTH18538
Husqvarna LTH18538 — Lawn tractor · 19 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
19 hp
Weight
178 kg
Hover a source tag to verify
Overview
ManufacturerHusqvarnaReference
Lawn tractorReference
Original price was $1,400 in 2012Reference
Two-wheel driveReference
SteeringmanualReference
Open operator station with medium-back vinyl seat.Reference
Engine
18.5HP Briggs & Stratton 499cc 1-cyl gasolineReference
Fuel tank5.7 LReference
Briggs & Stratton 31N707Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement30.5 ciReference
Power (gross)13.8 kWReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
SparkplugChampion RC12YCReference
Sparkplug gap0.762 mmReference
Oil capacity1.4 LReference
Oil change25 hReference
Transmission
hydrostaticReference
TransmissionTuff Torq K46Reference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
Oil changesealed unit, owner service is not recommendedReference
PTO & Hydraulics
Front PTOindependentReference
ClutchmanualReference
Dimensions
Wheelbase121 cmReference
Weight178 kgReference
Front tire15x6-6Reference
Rear tire20x8-8Reference
Lawn/turf front15x6-6Reference
Lawn/turf rear20x8-8Reference
Length175 cmReference
Width103 cmReference
Height105 cmReference
Front axleCast-ironReference
Husqvarna LTH18538 attachments
38" mid-mount mower deckReference
Electrical
GroundnegativeReference
Charging amps3 (battery)Reference
Charging amps5 (headlights)Reference
Battery CCA230Reference
Battery volts12Reference
Battery AH28Reference
Battery GroupU1RReference
38" Mower deck
Typemid-mount HusqvarnaReference
Type2-bladeReference
Cutting width96 cmReference
Overall width126 cmReference
Cut height3 to 10 cmReference
Cut positions6Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
