Tractor · Unverified
IMR Rakovica R 35 DV
IMR Rakovica R 35 DV — Utility tractor · 34 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
34 hp
Weight
1749 kg
Hover a source tag to verify
Overview
ManufacturerIMR RakovicaReference
Utility tractorReference
Built in Belgrade, SerbiaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Mechanical wet disc brakesReference
Two-post ROPS.Reference
Engine
1.5L 3-cyl dieselReference
Engine25.0 kWReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke84 x 90 mmReference
EmissionsStage 2Reference
Power25.0 kWReference
Fuel systemdirect-injectionReference
Rated RPM3000Reference
Torque96.0 NmReference
Torque RPM1800Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchronized gearReference
Typesynchronized gearReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
Pump flow39.0 lpmReference
Rear PTOliveReference
Rear PTO Type540Reference
Rear PTO Type540/750Reference
Rear PTO Type1000Reference
Dimensions
Wheelbase168 cmReference
Weight1749 kgReference
Front tire270/70R16Reference
Rear tire320/70R24Reference
Ag front270/70R16Reference
Ag rear320/70R24Reference
Ag front7.00x12Reference
Ag front6.10x16Reference
Ag front10x12Reference
Ag rear12.4x20Reference
Ag rear780/85R24Reference
Length294 cmReference
Width134 cmReference
Ground clearance23 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
