Tractor · Unverified
IMR Rakovica R 50 DV
IMR Rakovica R 50 DV — Utility tractor · 47 hp. Reference specifications; pending source verification.
The IMR Rakovica R 50 DV is a tractor model rated at 47 hp, which positions it at the lighter end of its class. It is equipped with a 3-cylinder diesel liquid-cooled engine, and features four-wheel drive with an 8-speed gearbox. The tractor has an operating weight of 1799 kg, and is suited to operations of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Weight
1799 kg
Catalogue coverage
Variants represented
2
Richest spec table
48 rows
Recorded power
47 hp
Recorded weight
1799 kg
Transmissions
8-speed synchronized gear
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerIMR RakovicaReference
Utility tractorReference
Built in Belgrade, SerbiaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Mechanical wet disc brakesReference
Two-post ROPS.Reference
Engine
2.1L 3-cyl dieselReference
Engine35.0 kWReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.1 LReference
Bore/Stroke94 x 100 mmReference
EmissionsStage 2Reference
Power35.0 kWReference
Fuel systemdirect-injectionReference
Rated RPM2600Reference
Torque145.1 NmReference
Torque RPM1200Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchronized gearReference
Typesynchronized gearReference
Gears8 forward and 4 reverseReference
Clutchdry discReference
PTO & Hydraulics
Pump flow39.0 lpmReference
Rear PTOliveReference
Rear PTO Type540Reference
Rear PTO Type540/750Reference
Rear PTO Type1000Reference
Dimensions
Wheelbase168 cmReference
Weight1799 kgReference
Front tire270/70R16Reference
Rear tire320/70R24Reference
Ag front270/70R16Reference
Ag rear320/70R24Reference
Ag front7.00x12Reference
Ag front6.10x16Reference
Ag front10x12Reference
Ag rear12.4x20Reference
Ag rear780/85R24Reference
Length294 cmReference
Width134 cmReference
Ground clearance23 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
