Tractor · 2003Unverified
IMR Rakovica R 75-12 BS DV
IMR Rakovica R 75-12 BS DV — Utility tractor · 60 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
60 hp
Weight
3250 kg
Hover a source tag to verify
Overview
ManufacturerIMR RakovicaReference
Utility tractorReference
Built in Belgrade, SerbiaReference
Four-wheel driveReference
Differential lockmechanical rearReference
Steeringhydrostatic powerReference
Trailer brakespneumaticReference
Cab standard with air-conditioning.Reference
Engine
IMR Rakovica 3.3L 4-cyl dieselReference
Fuel tank60.0 LReference
Engine47.0 kWReference
IMR Rakovica DM34TReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke91 x 127 mmReference
Power47.0 kWReference
Fuel systemdirect-injectionReference
Rated RPM2300Reference
Torque206.0 NmReference
Torque RPM1350Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed gearReference
TransmissionMT 280 12 BSReference
TypegearReference
Gears12 forward and 4 reverseReference
Clutchdry discsReference
Four gears (1-4) in three ranges (low, medium, high) plus reverse range.Reference
PTO & Hydraulics
PTO (claimed)45.0 kWReference
Typeopen centerReference
Pressure200.0 barReference
Valves2Reference
Pump flow29.9 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift (at ends)2039 kgReference
Rear PTOliveReference
Rear PTO Type540/750Reference
Dimensions
Wheelbase216 cmReference
Weight3250 kgReference
Front tire8.00-20Reference
Rear tire16.9-30Reference
Ag front8.00-20Reference
Ag rear16.9-30Reference
Length355 cmReference
Height (cab)246 cmReference
Front tread139 to 189 cmReference
Rear tread139 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
