Tractor · 2006Unverified
IMT 2070
IMT 2070 · 76 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
76 hp
Weight
4200 kg
Hover a source tag to verify
Overview
ManufacturerIMTReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
4.5L 4-cyl dieselReference
Engine56.3 kWReference
4045DF270Reference
dieselReference
4-cylinderReference
Displacement4.5 LReference
Bore/Stroke106 x 127 mmReference
Power56.3 kWReference
Rated RPM2300Reference
Transmission
10-speedReference
TransmissionsynchroReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
Rear lift3000 kgReference
Rear PTO Type540/1000Reference
Dimensions
Weight4200 kgReference
Front tire12.4-24Reference
Rear tire18.4-30Reference
Ag front12.4-24Reference
Ag rear18.4-30Reference
Length356 cmReference
Height270 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
