Tractor · Unverified

IMT 5133

Name: IMT 5133
Brand: IMT

IMT 5133 · 133 hp. Reference specifications; pending source verification.

The IMT 5133 is a tractor model with a power output of 133 hp, making it one of the more powerful machines in its class. It features a 6-cylinder turbocharged diesel engine, which is connected to a hydrostatic transmission and powers four-wheel drive. The tractor's weight is listed at 6026 kg. It is designed for operations on land areas of approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

133 hp

Weight

6026 kg

Catalogue coverage

Variants represented

Richest spec table

27 rows

Recorded power

133 hp

Recorded weight

6026 kg

Transmissions

10-speed

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerIMTReference

Four-wheel driveReference

Steeringhydrostatic powerReference

Disc brakesReference

Engine

5.8L 6-cyl dieselReference

Fuel tank260.0 LReference

Engine99.2 kWReference

TS 46/TReference

turbo dieselReference

6-cylinderReference

Displacement5.8 LReference

Bore/Stroke98 x 127 mmReference

Power99.2 kWReference

Rated RPM2250Reference

Transmission

10-speedReference

TransmissionsynchroReference

Gears10 forward and 2 reverseReference

PTO & Hydraulics

Total flow35.2 lpmReference

Rear lift3800 kgReference

Rear PTO Type540/1000Reference

Dimensions

Weight6026 kgReference

Front tire12.4-24Reference

Rear tire2x9.5-48Reference

Ag front12.4-24Reference

Ag rear2x9.5-48Reference

Length549 cmReference

Height281 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
