The IMT 5135 is a tractor with a rated output of 136 hp, categorising it among higher-powered machines in its class. It is powered by a 6-cylinder turbocharged diesel engine, driving through four-wheel drive with a hydrostatic transmission. The listed weight of the IMT 5135 is 6401 kg, and it is designed for tasks involving areas of approximately 200–800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
136 hp
Weight
6401 kg
Catalogue coverage
Variants represented
2
Richest spec table
27 rows
Recorded power
136 hp
Recorded weight
6401 kg
Transmissions
8-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerIMTReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
6.0L 6-cyl dieselReference
Fuel tank260.0 LReference
Engine101.4 kWReference
1006-6TReference
turbo dieselReference
6-cylinderReference
Displacement6.0 LReference
Bore/Stroke100 x 127 mmReference
Power101.4 kWReference
Rated RPM2200Reference
Transmission
8-speedReference
TransmissionsynchroReference
Gears8 forward and reverseReference
PTO & Hydraulics
Total flow35.2 lpmReference
Rear lift5000 kgReference
Rear PTO Type540/1000Reference
Dimensions
Weight6401 kgReference
Front tire12.4-24Reference
Rear tire18.4-38Reference
Ag front12.4-24Reference
Ag rear18.4-38Reference
Length513 cmReference
Height287 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
