Tractor · 1961Unverified

IMT 533

Name: IMT 533
Brand: IMT

IMT 533 · 35 hp. Reference specifications; pending source verification.

The IMT 533 is a compact tractor with a rated output of 35 hp, distinguishing it among peers of its class. It was manufactured between 1961 and 1988. The 3-cylinder diesel engine drives a 6-speed gearbox, and the tractor has a listed weight of 1516 kg. It is suitable for tasks covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

35 hp

Weight

1516 kg

Catalogue coverage

Variants represented

Richest spec table

23 rows

Recorded power

35 hp

Recorded weight

1516 kg

Transmissions

6-speed

Production years

1961-1988

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerIMTReference

Manual steeringReference

Engine

2.4L 3-cyl dieselReference

Engine26.1 kWReference

IM 033/TReference

dieselReference

3-cylinderReference

Displacement2.4 LReference

Bore/Stroke89 x 127 mmReference

Power26.1 kWReference

Rated RPM2000Reference

Transmission

6-speedReference

TransmissiongearReference

Gears6 forward and 2 reverseReference

PTO & Hydraulics

Rear PTO Type540Reference

Dimensions

Wheelbase183 cmReference

Weight1516 kgReference

Front tire5.00-16Reference

Rear tire11.2-28Reference

Ag front5.00-16Reference

Ag rear11.2-28Reference

Length296 cmReference

Height136 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
