Tractor · 1980Unverified

IMT 539

Name: IMT 539
Brand: IMT

IMT 539 · 39 hp. Reference specifications; pending source verification.

The IMT 539 is a tractor with a rated output of approximately 39 horsepower, positioning it within the lighter category of its class. Produced in 1980, it is equipped with a 3-cylinder diesel engine and two-wheel drive, paired with a 6-speed gearbox. The tractor's operating weight is listed as 1630 kg, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

39 hp

Weight

1630 kg

Catalogue coverage

Variants represented

Richest spec table

30 rows

Recorded power

39 hp

Recorded weight

1630 kg

Transmissions

6-speed

Production years

1980-1980

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerIMTReference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Engine

2.5L 3-cyl dieselReference

Fuel tank34.8 LReference

Engine29.1 kWReference

M 33/TReference

dieselReference

3-cylinderReference

Displacement2.5 LReference

Bore/Stroke91 x 127 mmReference

Power29.1 kWReference

Rated RPM2000Reference

Torque153.2 NmReference

Torque RPM1350Reference

Transmission

6-speedReference

TransmissiongearReference

Gears6 forward and 2 reverseReference

PTO & Hydraulics

Total flow15.9 lpmReference

Rear lift1100 kgReference

Rear PTO Type540Reference

Dimensions

Wheelbase182 cmReference

Weight1630 kgReference

Front tire6.00-16Reference

Rear tire11.2-28Reference

Ag front6.00-16Reference

Ag rear11.2-28Reference

Length296 cmReference

Height202 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
