The IMT 542 is a tractor with a rated power output of 42 horsepower, categorising it as a lighter model within its class. This model was manufactured in 1986. It features a 3-cylinder diesel engine paired with mechanical front-wheel drive and a 6-speed gearbox. The tractor has an operating weight of 2185 kg and is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Weight
2185 kg
Catalogue coverage
Variants represented
2
Richest spec table
31 rows
Recorded power
42 hp
Recorded weight
2185 kg
Transmissions
6-speed
Production years
1986-1986
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerIMTReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringpower optionalReference
Engine
2.5L 3-cyl dieselReference
Fuel tank50.0 LReference
Engine31.3 kWReference
M 33/TReference
dieselReference
3-cylinderReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power31.3 kWReference
Rated RPM2250Reference
Transmission
6-speedReference
10-speedReference
TransmissiongearReference
Gears6 forward and 2 reverseReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
Total flow18.2 lpmReference
Rear lift1400 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase198 cmReference
Weight2185 kgReference
Front tire6.00-16Reference
Rear tire12.4-28Reference
Ag front6.00-16Reference
Ag rear12.4-28Reference
Ag front7.50-20Reference
Length325 cmReference
Height229 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
