Tractor · 1980Unverified

IMT 547

Name: IMT 547
Brand: IMT

IMT 547 · 48 hp. Reference specifications; pending source verification.

The IMT 547 is a tractor rated at roughly 48 hp, which places it at the lighter end of its class. It ran in production from 1980 to 1986. It is powered by a 3-cylinder diesel engine, paired with a 10-speed gearbox. It has a listed operating weight of 2130 kg, and it suits operations of up to 200 ac. The available specification table below shows both UK and US units.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

48 hp

Weight

2130 kg

Catalogue coverage

Variants represented

Richest spec table

25 rows

Recorded power

48 hp

Recorded weight

2130 kg

Transmissions

10-speed

Production years

1980-1986

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerIMTReference

SteeringmechanicalReference

Engine

2.5L 3-cyl dieselReference

Fuel tank50.0 LReference

Engine35.8 kWReference

A3.152Reference

dieselReference

3-cylinderReference

Displacement2.5 LReference

Bore/Stroke91 x 127 mmReference

Power35.8 kWReference

Rated RPM2250Reference

Transmission

10-speedReference

Gears10 forward and 2 reverseReference

PTO & Hydraulics

Total flow18.2 lpmReference

Rear lift1400 kgReference

Rear PTO Type540Reference

Dimensions

Wheelbase198 cmReference

Weight2130 kgReference

Front tire7.50-16Reference

Rear tire12.4-32Reference

Ag front7.50-16Reference

Ag rear12.4-32Reference

Length340 cmReference

Height230 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
