Tractor · 1986Unverified
IMT 549
IMT 549 · 47 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Weight
2380 kg
Hover a source tag to verify
Overview
ManufacturerIMTReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringpower optionalReference
Engine
2.5L 3-cyl dieselReference
Fuel tank50.0 LReference
Engine35.0 kWReference
DM 33/TReference
dieselReference
3-cylinderReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power35.0 kWReference
Rated RPM2250Reference
Torque161.4 NmReference
Torque RPM1300Reference
Transmission
10-speedReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
Total flow32.9 lpmReference
Rear lift1400 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase198 cmReference
Weight2380 kgReference
Front tire6.00-16Reference
Rear tire12.4-28Reference
Ag front6.00-16Reference
Ag rear12.4-28Reference
Ag front7.50-20Reference
Length340 cmReference
Height246 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
