The IMT 565 is a tractor with an approximate engine power output of 63 hp, positioning it within the lower power range of its class. It was produced in 1986. The tractor is equipped with a 4-cylinder diesel engine and four-wheel drive, paired with a 6-speed gearbox. Its operating weight is specified at 3650 kg, suitable for use on areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
63 hp
Weight
3650 kg
Catalogue coverage
Variants represented
2
Richest spec table
33 rows
Recorded power
63 hp
Recorded weight
3650 kg
Transmissions
6-speed
Production years
1986-1986
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerIMTReference
Built in Belgrade, YugoslaviaReference
Two- or four-wheel driveReference
Power steeringReference
Disc brakesReference
Engine
IMR 3.3L 4-cyl dieselReference
Fuel tank96.1 LReference
Engine47.0 kWReference
IMR DM 34/TReference
dieselReference
4-cylinderReference
Displacement3.3 LReference
Bore/Stroke91 x 127 mmReference
Power47.0 kWReference
Rated RPM2250Reference
Torque217.0 NmReference
Torque RPM1350Reference
Transmission
6-speedReference
TransmissiongearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Total flow18.2 lpmReference
Total flow32.9 lpmReference
Rear lift1900 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase221 cmReference
Weight3650 kgReference
Front tire7.50-16Reference
Rear tire16.9-28Reference
Ag front7.50-16Reference
Ag rear16.9-28Reference
Ag front9.5-24Reference
Length391 cmReference
Height263 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
