The IMT 569 is a compact tractor rated at 63 hp, making it suitable for smaller-scale operations. It was manufactured in 1986, and its power source is a 4-cylinder diesel engine, driving through mechanical front-wheel drive with a hydrostatic transmission. The listed weight of the IMT 569 is 3650 kg, and it is designed for tasks covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
63 hp
Weight
3650 kg
Catalogue coverage
Variants represented
2
Richest spec table
32 rows
Recorded power
63 hp
Recorded weight
3650 kg
Transmissions
10-speed
Production years
1986-1986
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerIMTReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD optionalReference
Steeringhydrostatic powerReference
Disc brakesReference
Engine
3.3L 4-cyl dieselReference
Fuel tank96.1 LReference
Engine47.0 kWReference
DM 34/TReference
dieselReference
4-cylinderReference
Displacement3.3 LReference
Bore/Stroke91 x 127 mmReference
Power47.0 kWReference
Rated RPM2250Reference
Torque217.0 NmReference
Torque RPM1350Reference
Transmission
10-speedReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
Total flow18.2 lpmReference
Total flow32.9 lpmReference
Rear lift1900 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase221 cmReference
Weight3650 kgReference
Front tire7.50-16Reference
Rear tire16.9-28Reference
Ag front7.50-16Reference
Ag rear16.9-28Reference
Ag front9.5-24Reference
Length391 cmReference
Height263 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
