Lawn Tractor · 1991Unverified
Ingersoll 1112
Ingersoll 1112 — Lawn tractor · 12 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Weight
158 kg
Hover a source tag to verify
Overview
ManufacturerIngersollReference
Lawn tractorReference
Built in Winneconne, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
1112Ggear driveReference
1112HhydrostaticReference
Engine
12HP Briggs & Stratton 459cc 1-cyl gasolineReference
Fuel tank3.8 LReference
Briggs & Stratton 283707Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement28.04 ciReference
Bore/Stroke87 x 78 mmReference
Power (gross)8.9 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
hydrostaticReference
Gear Lawn/turf rear18x9.50-8Reference
Typebelt-driven gearReference
Gears6 forward and 1 reverseReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Mid PTO TypepulleyReference
Dimensions
Weight158 kgReference
Front tire15x6.00-6Reference
Rear tire18x9.50-8Reference
Lawn/turf front15x6.00-6Reference
Hydro Lawn/turf rear20x10.00-8Reference
Ingersoll 1112 attachments
39" mid-mount mower deckReference
bladeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
39" mid-mount mower deckReference
BladeReference
39" Mower deck
Typemid-mount IngersollReference
Type2-blade with manual liftReference
Cutting width99 cmReference
DrivebeltReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
