Lawn Tractor · 1992Unverified
Ingersoll 2014
Ingersoll 2014 · 14 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
14 hp
Hover a source tag to verify
Overview
ManufacturerIngersollReference
Built in Winneconne, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
14HP Briggs & Stratton 480cc 2-cyl gasolineReference
Briggs & Stratton 294777Reference
gasolineReference
2-cylinderReference
air-cooled vertical-shaftReference
Displacement29.3 ciReference
Bore/Stroke68 x 66 mmReference
Power10.4 kWReference
Rated RPM3600Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
Typebelt-driven hydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Dimensions
Front tire15x6.00-6Reference
Rear tire20x10.00-8Reference
Lawn/turf front15x6.00-6Reference
Lawn/turf rear20x10.00-8Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
