Lawn Tractor · 1993Unverified
Ingersoll 3118D
Ingersoll 3118D — Garden tractor · 18 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
18 hp
Hover a source tag to verify
Overview
ManufacturerIngersollReference
Garden tractorReference
Two-wheel driveReference
Power steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
18HP Perkins 699cc 3-cyl dieselReference
Perkins 103.07Reference
dieselReference
3-cylinderReference
liquid-cooled horizontal-shaft inlineReference
Displacement42.7 ciReference
Bore/Stroke66 x 64 mmReference
Power (gross)13.4 kWReference
Fuel systemindirect injectionReference
Compression24:1Reference
Firing order1-2-3Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydraulic driveReference
TransmissionHy-DriveReference
Typehydraulic driveReference
Gearsinfinite forward and reverse (2-range)Reference
Capacities
Fuel11.4 LReference
PTO & Hydraulics
Hydraulic system5.7 LReference
Typeopen centerReference
Capacity5.7 LReference
Pressure193.1 barReference
Rear valves2Reference
Pump flow36.0 lpmReference
Total flow52.0 lpmReference
Steering flow8.5 lpmReference
Steering press.49.6 barReference
Dimensions
Wheelbase116 cmReference
Front tire16x6.50-8Reference
Rear tire23x10.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x10.50-12Reference
Length165 cmReference
Width104 cmReference
Height (steering wheel)101 cmReference
Height (hood)90 cmReference
Front tread73 cmReference
Rear tread70 cmReference
Ingersoll 3118D attachments
44" mid-mount mower deckReference
48" mid-mount mower deckReference
60" mid-mount mower deckReference
snowblowerReference
bladeReference
3118D Serial Numbers
Location:Serial number plate on the left side of the tractor, above the foot rest.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
44" mid-mount mower deckReference
48" mid-mount mower deckReference
60" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
