Lawn Tractor · 1997Unverified
Ingersoll 6020
Ingersoll 6020 · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
1380 to 3040 pounds
Hover a source tag to verify
Overview
ManufacturerIngersollReference
Built in Winneconne, Wisconsin, USAReference
Two-wheel driveReference
Steeringhydraulic powerReference
Mechanical band brakesReference
Open operator station.Reference
Variants
60202WDReference
70204WDReference
Engine
20HP Honda 614cc 2-cyl gasolineReference
20HP Kohler 640cc 2-cyl gasolineReference
Honda GX620Reference
gasolineReference
2-cylinderReference
air-cooled horizontal-shaft V-TwinReference
Displacement37.5 ciReference
Bore/Stroke77 x 66 mmReference
Power (gross)14.9 kWReference
Rated RPM3600Reference
Torque44.1 NmReference
Torque RPM2500Reference
StarterelectricReference
Starter volts12Reference
Sparkplug gap0.762 mmReference
Oil capacity1.2 LReference
Oil change100 hReference
Kohler CH20Reference
air-cooledReference
Displacement39.1 ciReference
Bore/Stroke77 x 67 mmReference
Oil capacity1.9 LReference
Capacities
Fuel24.2 LReference
PTO & Hydraulics
Hydraulic system18.9 LReference
Typeopen centerReference
Capacity18.9 LReference
Pressure172.4 barReference
Total flow50.7 lpmReference
Dimensions
Wheelbase121 cmReference
Weight1380 to 3040 poundsReference
Front tire18x8.50-8Reference
Rear tire29x12.50-15Reference
Lawn/turf front18x8.50-8Reference
Lawn/turf rear29x12.50-15Reference
Length250 cmReference
Length406 cmReference
Width121 cmReference
Shipping weight625 kgReference
Shipping weight1378 kgReference
Ingersoll 6020 attachments
front-end loaderReference
backhoeReference
Electrical
Charging system15Reference
Charging ampsalternatorReference
Battery CCA300Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Ingersoll 6020 Backhoe
Backhoe typeIngersoll 6020 BackhoeReference
Transport height182 cmReference
Digging depth233 cmReference
Reach from pivot284 cmReference
Swing Arc180°Reference
Transmission
TransmissionHy-driveReference
Gearsinfinite forward and reverse (2-range)Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
