Lawn Tractor · 1991Unverified
Ingersoll 808
Ingersoll 808 — Riding lawn mower · 8 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
8 hp
Weight
140 kg
Hover a source tag to verify
Overview
ManufacturerIngersollReference
Riding lawn mowerReference
Built in Winneconne, Wisconsin, USAReference
Two-wheel driveReference
Manual steeringReference
Mechanical disc brakesReference
Open operator station.Reference
Variants
80RTsimilar Massey Ferguson modelReference
Engine
8HP Briggs & Stratton 318cc 1-cyl gasolineReference
Fuel tank3.8 LReference
Briggs & Stratton 193707Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement19.44 ciReference
Bore/Stroke76 x 70 mmReference
Power (gross)6.0 kWReference
StarterelectricReference
Starter volts12Reference
Transmission
5-speed gearReference
TransmissionPeerless 700-047Reference
Typebelt-driven gearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Mid PTOindependentReference
ClutchmanualReference
Mid PTO TypepulleyReference
Dimensions
Wheelbase119 cmReference
Weight140 kgReference
Front tire11x4.00-5Reference
Rear tire16x6.50-8Reference
Lawn/turf front11x4.00-5Reference
Lawn/turf rear16x6.50-8Reference
Length205 cmReference
Height (steering wheel)91 cmReference
Ingersoll 808 attachments
30" mid-mount mower deckReference
808 Serial Numbers
Location:Serial number decal on the left side of the frame.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
30" Mower deck
Typemid-mount IngersollReference
Type1-blade with manual liftReference
Cutting width76 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
