Tractor · 1954Unverified

International Harvester 100

Name: International Harvester 100
Brand: International Harvester

International Harvester 100 — Utility tractor · 20 hp. Reference specifications; pending source verification.

The International Harvester 100 is a tractor with an approximate power output of 20 hp, positioning it at the lower end of its class. It was manufactured between 1954 and 1956. The tractor features a 4-cylinder petrol liquid-cooled engine and a 4-speed gearbox with two-wheel drive. Its listed operating weight is 1179 kg, and it is suitable for operations spanning up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

20 hp

Max power

13.3 kW

Weight

1179 kg

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

20 hp

Recorded weight

1179 kg

Transmissions

4-speed sliding gear

Production years

1954-1956

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerInternational HarvesterReference

Utility tractorReference

Built in Louisville, Kentucky, USAReference

Total built135Reference

Original price was $1,800 in 1956Reference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Variants

International 100utility tractorReference

Farmall 100row-crop tractorReference

Engine

International Harvester 2.0L 4-cyl gasolineReference

Fuel tank41.6 LReference

Drawbar (claimed)13.3 kWReference

Drawbar (tested)13.3 kWReference

Belt (tested)15.0 kWReference

International Harvester C-123Reference

gasolineReference

4-cylinderReference

liquid-cooledReference

Displacement2.0 LReference

Bore/Stroke79 x 102 mmReference

Air cleaneroil bathReference

Compression6.5:1Reference

Rated RPM1400Reference

Firing order1-3-4-2Reference

Starter volts6Reference

Oil capacity4.7 LReference

Belt power (max)15.0 kWReference

Max power13.3 kWReference

Transmission

4-speed sliding gearReference

Typesliding gearReference

Gears4 forward and 1 reverseReference

PTO & Hydraulics

PTO (claimed)15.0 kWReference

Dimensions

Wheelbase180 cmReference

Weight1179 kgReference

Front tire5.00-16Reference

Rear tire9-24Reference

Ag front5.00-16Reference

Ag rear9-24Reference

Shipping weight1179 kgReference

International Harvester 100 attachments

front-end loaderReference

100 Serial Numbers

Location:Clutch housing, left sideReference

1954501Reference

1955504Reference

1956575Reference

Final635Reference

FAQ: How to read a serial number table.Reference

Test results

Gasoline 4-speed 2WDLink: Nebraska Tractor Test 537 fileReference

Belt fuel use (max)7.9 l/hourReference

Drawbar performanceReference

Gear 2 used for power test.Reference

Max pull1135 kgReference

Gear 1 used for pull test.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
