Tractor · 1954Unverified
International Harvester 100
International Harvester 100 — Utility tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Max power
13.3 kW
Weight
1179 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Utility tractorReference
Built in Louisville, Kentucky, USAReference
Total built135Reference
Original price was $1,800 in 1956Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
International 100utility tractorReference
Farmall 100row-crop tractorReference
Engine
International Harvester 2.0L 4-cyl gasolineReference
Fuel tank41.6 LReference
Drawbar (claimed)13.3 kWReference
Drawbar (tested)13.3 kWReference
Belt (tested)15.0 kWReference
International Harvester C-123Reference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.0 LReference
Bore/Stroke79 x 102 mmReference
Air cleaneroil bathReference
Compression6.5:1Reference
Rated RPM1400Reference
Firing order1-3-4-2Reference
Starter volts6Reference
Oil capacity4.7 LReference
Belt power (max)15.0 kWReference
Max power13.3 kWReference
Transmission
4-speed sliding gearReference
Typesliding gearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
PTO (claimed)15.0 kWReference
Dimensions
Wheelbase180 cmReference
Weight1179 kgReference
Front tire5.00-16Reference
Rear tire9-24Reference
Ag front5.00-16Reference
Ag rear9-24Reference
Shipping weight1179 kgReference
International Harvester 100 attachments
front-end loaderReference
100 Serial Numbers
Location:Clutch housing, left sideReference
1954501Reference
1955504Reference
1956575Reference
Final635Reference
FAQ: How to read a serial number table.Reference
Test results
Gasoline 4-speed 2WDLink: Nebraska Tractor Test 537 fileReference
Belt fuel use (max)7.9 l/hourReference
Drawbar performanceReference
Gear 2 used for power test.Reference
Max pull1135 kgReference
Gear 1 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
