Industrial Tractor · Unverified
International Harvester 125B
International Harvester 125B — Crawler Loader · 70 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Weight
8550 kg
Hover a source tag to verify
Overview
ManufacturerInternational HarvesterReference
Crawler LoaderReference
Built in Doncaster, EnglandReference
DrivecrawlerReference
Final drivesplanetaryReference
Engine
International Harvester 3.9L 4-cyl dieselReference
Fuel tank115.8 LReference
Engine52.2 kWReference
International Harvester D-239Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 129 mmReference
Power52.2 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Rated RPM2500Reference
Torque225.1 NmReference
Torque RPM1600Reference
Starter typeelectricReference
Coolant capacity18.2 LReference
Transmission
2-speed power shuttleReference
Typepower shuttleReference
Gears2 forward and reverseReference
Oil capacity119.1 LReference
PTO & Hydraulics
Typeopen centerReference
Pressure137.9 barReference
Pump flow120.4 lpmReference
Dimensions
Weight8550 kgReference
14-inch tracksReference
Length430 cmReference
Height (steering wheel)231 cmReference
Height (cab)255 cmReference
Operating weight8550 kgReference
Ground clearance18 cmReference
Gauge137 cmReference
International Harvester 125B attachments
front-end loaderReference
International Harvester 125B Tracks
Width35 cmReference
Length on ground199 cmReference
Area on ground1.4 m²Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
